Description
Gravity Forms SWISS QR-Bill for Gravity PDF
Gravity Forms SWISS QR-Bill for Gravity PDF is a complete Swiss QR-bill to the PDF your form already produces: the payment part and the receipt, 210 × 105 mm on the lower cut edge, with the Swiss QR Code at exactly 46 × 46 mm and the Swiss cross in the middle. Your customer scans it with any banking app, or cuts it off and hands it in at the counter.
Built to the Implementation Guidelines QR-bill version 2.4, in force from 14 November 2026 — the version most implementations have not caught up with yet. And verified against the standard’s own worked examples rather than against a reading of it.
Key features
Geometry you can measure
These are not approximations — they were read back out of a produced PDF:
- Swiss QR Code exactly 46 × 46 mm with no quiet zone inside it, error correction level M, and at least 5 mm of clear space on every side.
- Module size 0.667 mm for a typical payload, comfortably above the 0.4 mm the standard requires for reliable scanning.
- Swiss cross 7 × 7 mm, centred exactly on the code.
- Amount box 40 × 15 mm on the payment part and 30 × 10 mm on the receipt; payer box 65 × 25 mm and 52 × 20 mm; corner marks at 0.75 pt.
- Acceptance point area 20 mm high, “Acceptance point” right-aligned as prescribed.
